Complete Pump with Adjustable Speed AC Electric Motor

Pump with oil filled, ball bearing, steel gear transmission mounted on 8" x 20" aluminum channel with 1/2 HP, 70 to 1800 RPM adjustable solid state control, 115 V, 60 Hz, single phase motor. Includes pulleys, belt and belt guard.

FLOW RATE BY TUBING SIZE
Gal./Hr. & Liters/Min.
Model No.
Gearbox Ratio
Pulley Ratio
Pump RPM
3/8" ID
1/2" ID
5/8" ID
3/4" ID
110-2-4E1E3E
14/1
1/1.5
7.5-193.0
3.7-95.0
0.2-6.0
6.1-158.0
0.4-10.0
9.7-250.0
0.6-15.8
16.4-423.0
1.0-26.7


110-43E









Dimension Drawing
Exploded Parts Driagram
HOW TO ORDER THE RIGHT TAT HIGH CAPACITY PUMP TO MEET YOUR SPECIFIC PUMPING NEEDS...
  • Specify Model Number: 110-030, 110-#3A, 110-43E, etc.
  • Specify Tubing Material: Neoprene, Hypalon, etc.
    NOTE: Choose proper Tubing material for fluid to be pumped using Chemical Resistance Chart.
  • Specify Motor Type for Fixed-Speed Electric Pumps by substituting 1, 2, or 3 for # sign (1 for open frame motor, 2 for totally enclosed motor, 3 for explosion-proof motor).
  • All Series 110 Pumps supplied with roller assembly adjustable for 3/32", 1/8", 5/32", and 3/16" tubing wall thickness.
